| Model | RT80 Rotary Drilling Rig | |
| Power System | Engine Type | Weichai WP4.1 |
| Engine Speed (kw/rpm) | 103/2000 | |
| Hydraulic System | Main Pump | Kawasaki |
| Main Valve | Italy | |
| Rotary Valve Assembly | Korea SUNJIN | |
| Walking assembly | PMP/Italy | |
| Main winch Motor | German Rexroth/Shanghai Electric | |
| Vice winch Assembly | Korea KYG | |
| Power Head Reducer | Fuller | |
| Power Head Motor Model | Shanghai Electric | |
| Central Rotary Joint | MCN6-18HT | |
| Other configuration | With kelly bar | （√）yes （）no |
| With Air Conditioner | （√）yes （）no | |
| Main winch wire rope | ￠20mm | |
| Vice winch wire rope | ￠16mm | |
| Kelly bar type | ￠299-4×7m | |
| Other | ||
| Max.Drilling Dia. | 1200mm | |
| Max.Drilling Depth | 24m | |
